Input + to Battery +, Input- to Battery-.
Output + to load +, Output- to Load-.
Never reverse the input polarity or it damages your fuses or converter.
This one can’t be used in tele-communication, medical, aerospace and military. if you need these request, please give us message.
DC 36V/48V Battery Vehicles and boats
Output side only connects DC loads
Notes:
This converter can not be connected to solar panels or wind turbine directly.
Wide input voltage from 30V to 60V
Stable output voltage is 12V
100% actual photos
100% full rated power
100% full stable output Current
100% burn-in test
High efficiency
IP68 Waterproof
Cooling by free air convection
Over current protection, Over voltage protection
Over temperature shutdown, Short circuit protection, Output reverse polarity protection
Dimension: 2.91*2.91*1.22 inch
Net Weight: 0.6 lb
