NOT:The main figure is only as a reference, please refer to the size of the detailed size chart
Qty:1pcs linear actuator
Product composition:
1 Stroke: 200 mm
2 Speed: 5mm/s (Speed trip can be customized, the maximum Speed of 20 mm/s)
3 Maximum thrust: 1500 N
4 the relationship between speed and the force: 5 mm/s (1500 N) – 20mm/s (750N)
5 Ambient temperature: -26?? C — +65 ?? C
6 Standard of protection: IP54
7 built – in limit switches
8 Low noise design, the noise level 45 db below
10 – Mounting dimensions (putter fully retracted to the short between the front two holes, namely putting their length), L (Mounting dimensions) = S (stroke) + 100 mm;
Putter is fully extended to the short between the front and rear two holes, = 2 s (stroke) + 100 mm;
11 can be equipped with wired remote control or stepping device (the Need to buy)
Product features: driven by other objects to push, pull, Rising and falling of the action
Product Applications: Automotive, lifts, massage beds,
