Product example for shock absorber
Please note that this picture may differ from the actual product application
S46HR1C1S
Single tube
Piston diameter: 46 mm
Monotube high pressure gas type of shock absorber with hose mounted external reservoir
Adjustable rebound damping on single tube shocks.
Adjuster wheel above the end eye
Adjustable compression damping.
Adjuster wheel or slot on the reservoir
Hose mounted hydraulic spring preload adjuster
Length: 323,5 mm Stroke: 62,5 mm Rate N/mm: 120 N/mm Mounted spring: 01095-44
