8-Piece Fuel Injector Set (Part #0280150718) for Ford F-150/F-250/F-350 with 4.6L & 5.4L Engines
8-Piece Fuel Injector Set (Part #0280150718) for Ford F-150/F-250/F-350 with 4.6L & 5.4L Engines - Image 2
8-Piece Fuel Injector Set (Part #0280150718) for Ford F-150/F-250/F-350 with 4.6L & 5.4L Engines - Image 3
8-Piece Fuel Injector Set (Part #0280150718) for Ford F-150/F-250/F-350 with 4.6L & 5.4L Engines - Image 4
8-Piece Fuel Injector Set (Part #0280150718) for Ford F-150/F-250/F-350 with 4.6L & 5.4L Engines - Image 5

8-Piece Fuel Injector Set (Part #0280150718) for Ford F-150/F-250/F-350 with 4.6L & 5.4L Engines

SKU GJ.22242 280150718 Category Tag

8-Piece Fuel Injector Set (Part #0280150718) for Ford F-150/F-250/F-350 with 4.6L & 5.4L Engines

Description

Fuel Injector Description
Features:
Injector Design: Metal and composite plastic
Orifice Type: 4-hole disc
Connector Type: EV1 Jetronic
O-Ring: Pre-installed
Filter Design: Basket filter at inlet
Spray Pattern: 15-degree spray cone
Specifications:
Coil Resistance: 14.5 Ohms (High Impedance)
Static Flow Rate: 215cc/min at 43PSI
Gain: 0.12ms/MG
Offset: 0.055ms
Turn-On Time @ 14VDC: 1.14ms
Turn-Off Time: 0.85ms @ 300KPa
Amperage: 1.0 Amps
Pressure Range: Min 30PSIG / Max 100PSIG
Variance: 2%
Length: 3″ (74mm)
O-Ring to O-Ring Length: 2.5″ (63mm)
Diameter: 16mm
O-Ring Diameter: 14.5mm
Replaces Part Numbers:
280150943, 0280150939, 0280150909, 0280150943, 0280150718, 0280150956, 822-11111, F1ZE-C2A, E6TE-A2B, E5TE-A3B, E6TE-A3B
Fitment:
Ford Vehicles:
1986ÿ1996 Ford 5.0L V8
1988ÿ1996 Ford 5.8L V8
1992ÿ1998 Ford Crown Victoria 4.6L V8
1987ÿ1996 Ford E-150 5.0L V8
1997ÿ2003 Ford E-150 4.6L / 5.4L V8
1988ÿ1996 Ford E-150 5.8L V8
2004 Ford E-150 Super Duty 5.4L V8
1987ÿ1991 Ford E-250 5.0L V8
1997ÿ2002 Ford E-250 5.4L V8
1988ÿ1996 Ford E-250 5.8L V8
1997ÿ1998 Ford E-350 5.4L V8
1988ÿ1996 Ford E-350 5.8L V8
1999ÿ2002 Ford E-350 Super Duty 5.4L V8
2000ÿ2005 Ford Excursion 5.4L V8
Package Includes:
8x Fuel Injectors
