Premium Quality Replacement Part
Clutch Friction with Steel Plates and Springs Gasket Kit
For Honda Models:
CRF250L 2013-2020
CRF250LA 2017-2020
CRF250RL 2017-2020
CRF250RLA 2017-2020
Order Includes:
4 x Clutch Friction Plate Kevlar : 22201-KYJ-902 22201-MGZ-J01
Inner Diameter : 100.8 mm | 3.97″
Outer Diameter : 124.8 mm | 4.91″
Thickness : 2.33 mm | 0.09″
18 Teeth
Kevlar is a high durability material more resistant to hard use.
1 x Clutch Friction Plate Kevlar : 22202-KZZ-901
Inner Diameter : 111.15 mm | 4.37″
Outer Diameter : 125.3 mm | 4.93″
Thickness : 2.45 mm | 0.09″
18 Teeth
4 x Clutch Steel Plate : 22321-KYJ-902 22322-KZZ-901
Inner Diameter : 100.8 mm | 3.96″
Outer Diameter : 125.5 mm | 4.94″
Thickness : 1.4 mm | 0.055″
30 Teeth
5 x Clutch Spring : 22401-KYJ-902
Length : 41.84 mm | 1.64″
Width : 18.98 mm | 0.74″
Item Thickness : 2.38 mm | 0.09″
1 x Clutch Cover Gasket : 11394-K87-A30 11394-KYJ-900
