CV Axle Set for Can-Am Maverick XMR 1000 4×4 2016-2018

Product categories
Product tags
air filter axle bearing belt bolt bracket brake brake cable brake disc brake disk carburetor car lamp car light centrifugal clutch clutch clutch cable clutch parts cylinder kit dipstick disc-brake disc brakes disk brake drive belt front fork gasket holder John Deere Parts Lamps latch Lawnmower Blade Lift Kit Lights lowering kit oil seal protective cover rim seat shaft shock absorber starter motor switch throttle cable tool washer wheel hub
CV Axle Set for Can-Am Maverick XMR 1000 4x4 2016-2018
CV Axle Set for Can-Am Maverick XMR 1000 4x4 2016-2018 - Image 2
CV Axle Set for Can-Am Maverick XMR 1000 4x4 2016-2018 - Image 3

CV Axle Set for Can-Am Maverick XMR 1000 4×4 2016-2018

SKU Z.20590 705401387, 705401388, 705502414 Category Tags ,

CV Axle Set for Can-Am Maverick XMR 1000 4×4 2016-2018

Description

This is a set of new CV axles for a Can-Am Maverick XMR.

They fit the following models:

2016-2018 Maverick 1000R XMR

2017-2018 Maverick MAX 1000R XMR

*Axles made as an OE replacement, and is not intended for lifted/ modified vehicles

Product features:

Stronger than OEM chromoly forged steel axle bars

Greased with a moly based grease to provide superior joint lubrication

Fitted with neoprene CV boots for added wear and puncture resistance

Includes 4 fully-assembled CV axles

Inboard CV joint spline count: Front – 21, Rears – 24

Outboard CV joint spline count: Fronts – 26, Rears – 29

Compressed overall axle length (mm): FL – 730.5, FR- 773, BR = 760

Replaces OEM # FL – 705401387, 705401663, FR – 705401388, 705401878, BR – 705502351, 705502414
