Fitment Chart:
Years Make Model Transmission Notes
1988-1989 Toyota MR2 Automatic 4AGELC Eng.
1987 Toyota MR2 Automatic
Specifications:
Part Category: CV Axle Shaft
Manufacturer Part Number: TO-8360
Vehicle Position: Rear Driver Side
Placement on Vehicle: Rear Left
Label: CV Axle Shaft
Product Type: Factory Replacement
Type: CV Axle Shaft
Number of Pieces: 1
Abs Tone Ring Included: No
Axle Nut Head Type: Hex
Axle Nut Height (in): 3/7
Axle Nut Height (mm): 11
Axle Nut Hex Size (in): 1 1/6
Axle Nut Hex Size (mm): 29.8
Axle Nut Included: Yes
Axle Nut Length (in): 1 1/3
Axle Nut Length (mm): 34.4
Axle Nut Locking Type: Standard
Axle Nut Thread Size: M19*1.5
Boot Material: Neoprene
Inboard Joint Type: Flange
Inboard Shaft Connection Style: Flange
New Or Remanufactured: New
Number Of Outboard Splines: 26
Outboard Joint Type: Conventional
Outboard Shaft Connection Style: Spline
Overall Compressed Length (in): 20.24
Overall Compressed Length (mm): 514
Interchange Part Number: 44306SDRA00 60-5122 TO-8360
Brand Label: CV Axle Shaft
