Premium Quality Replacement Part
Front & Rear CV Joint Axle
Compatible with Arctic Cat Models :
1000 Mud Pro 2012-2014
1000 XT 2013-2014
1000 H2 2011
TRV 1000 2011-2014
TRV 1000 Cruiser 2011-2012
TRV 1000 GT 2012
TRV 1000 LTD 2013-2014
650 H1 2011
650 H1 Mud Pro Cat 2011
700 H1 Mud Pro 2011
700 Mud Pro 2012-2014
Order Includes :
2x Front Left or Right CV Joint Axle : 1502-942, 1502-805, 1502-943, 1502-806
Length : 584.2mm – 23.0 in
Spline A Length : 18.5mm – 0.72 in
Spline A Boot Width : 91.5mm – 3.60 in
Spline A – 28 Tooth
Spline B Length : 30.0mm – 1.18 in
Spline B Boot Width : 90.5mm – 3.56 in
Spline B – 24 Tooth
2x Rear Left & Right CV Joint Axle : 1502-941, 1502-723, 1502-804
Length : 577.85mm – 22.75 in
Spline A Length : 16.25mm – 0.63 in
Spline A Boot Width : 88mm – 3.46 in
Spline A – 27 Tooth
Spline B Length : 30.3mm – 1.19 in
Spline B Boot Width : 79mm – 3.11 in
Spline B – 27 Tooth
