Included Displays: Speedometer, Tachometer, Oil Pressure, Water Temp, Voltmeter, Fuel Level.

Also shown in digital message center: Odometer, Trip Odometer, Resettable Service Odometer, Clock, Hour Meter, 0-60 MPH Timer…

Various Indicators can be displayed: Turn Signals, High Beam, Check Engine, Parking Brake, Cruise Control??

Necessary sensors included for oil pressure (1/8?? NPT), Water Temp (1/8″ with bushings for 1/4″, 3/8″, 1/2?? NPT as well 12mm and 16mm for GM & LS applications) and speedometer pulse generator.

VHX-88C-PU-C-R (carbon fiber style/red backlighting is compatible with 1988-94 Chevy/GMC Pickup (and 1992-94 SUVs). System replaces the entire factory instrument cluster and lens assembly, fully remade with a billet aluminum housing and optical grade polycarbonate lenses.
Product Description
Compatible with 1988-94 Chevy/GMC Pickup (and ’92-94 SUV’s), the perfect platform for your dream truck: good looks with a variety of drivetrain options are keeping the CK trucks hot. Once you’ve stuffed yours full of the fire-breather of your choice, monitor your monster with this direct-fit instrument system.Complete with sending units, your dated 90’s dash will never be the same!System replaces the entire factory instrument cluster and lens assembly, fully remade with a billet aluminum housing and optical grade polycarbonate lenses.Fully lit needles, backlit faces, and highly visible LCD message centers are a few of the things that you can see which set the VHX Series apart from yesterday??s traditional approach to instrumentation. A few of the features which you don??t normally see are the micro-controlled precision stepper motors, solid state sensors for unparalleled accuracy, and user-customizable display feedback, all supported by an unrivaled limited lifetime warranty which has become the standard for Dakota Digital instrumentation systems. Completely engineered and manufactured at their facility in Sioux Falls, South Dakota, the VHX Series has completely revolutionized the instrumentation industry!Analog Gauges: Speedometer – 0-160 MPH
Tachometer – 0-8000 RPM
Oil Pressure – 0-80 psi
Water Temperature – 100-260oF
Fuel Level – E, 1/4, 1/2, 3/4, F
Voltmeter – 9-17 VDC Digital Message Centers:Standard Displays:-Odometer (One time user settable, Million Mile)
-Dual (A/B) Trip Meter (0- 9,999.9)
-Clock (12 hour) Performance Meters: -0-60 MPH Timer (0- 100 kmh)
-1/4 mile time
-1/4 mile end speed (trap speed)
-High speed recall
-High RPM recall Built-In Indicators: -Turn Signals (Left/ Right)
-High Beam
-Check Engine
-Parking Brake
-Cruise Control (On/ On & Engaged when vehicle is equipped)
-Gear Position (Optional GSS-3000 sensor required, sold separately)…
