Product Description:
Voltage Regulator Rectifier Fit For Honda VT500C/F VT700 Shadow 500 700 83-85 CBX400 NV400 FEATURES:
Direct replacement to your original unit.
Plug-and-play, direct fit, easy installation.
No assembly required.
Higher grade of electric components.
Improved heat sink and charging capabilities. SPECIFICATIONS:
Condition: Aftermarket 100% Brand New
Quanity: 1 PC
Type: Voltage Regulator RectifierDimensions:
Length(MAX): 127mm / 5.01 inches
Length(MIN): 69mm / 2.73 inches
Width: 73mm / 2.89 inches
Height: 23.7mm / 0.93 inches
Fixation Holes Distance: / 3.15 inchesOther Specifications:
Number of plug interface pins: 8
Number of Plugs: 2
Number of Wires: 8
PART NUMBER(S):
31600-MF5-018
31600-ME9-008 FITMENT:
For Honda VT500C Shadow 500 1983-1986
For Honda VT500F Shadow 500 1983-1984
For Honda VT700 Shadow 700 1983-1985
For Honda VT750C 1982-1984
For Honda CBX400 Custom 1983
For Honda NV400 Custom 1985 PACKAGE INCLUDED:
1 Voltage Regulator Rectifier NOTICE:
Before installing your new voltage regulator rectifier;

Check the AC output of the stator.

Replace any burned or corroded connectors on stator and regulator/rectifier

Check and repair any melted wiring.

Use hi-temp dielectric grease on all connectors.
