Fitment list
2012-2013 Kawasaki Teryx4 750
2014-2023 Kawasaki Teryx4 800
2014-2023 Kawasaki Teryx 800
Specifications of Winch Mounting Bracket
Item: UTV Winch Mounting Bracket
Material: Heavy-Duty Steel
Process: Black Powder Coated
Condition:100% Brand New
Specifications of Wireless Winch Remote Control
Color: blue
Power voltage:12V
Remote Range: about 100ft??30M??
Remote hand quantity: 2 Pcs
Total quantity:3 Pcs
Remote size: about 45 x 105 x 30mm
Receiver size: about 45 x 60 x 23mm
?̡?Package list??
1 X Winch Mounting Plate
1 X Installation Instruction
2 x Remotes
1 x Receiver
Designed to work with the following winches:
KFI: ST17 / A2000 / A2500-R2 / A3000 / U45-R2 / U45w-R2 / SE25 / SE35 / SE45-R2 / SE45w-R2 (U45w-R2 and SE45w-R2 will NOT work on 2014-19 models)
KFI: AM-25 / AM-35 / AS-25 / AS-35
KFI: AS-50 / AS-50w
WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
WARN: RT40 / XT40
WARN: Vantage 2000-3000lb (Will NOT work with Vantage 4000 due to motor lead orientation)
WARN: ProVantage 2500-4500lbs
ProVantage 3500 and 4500 will require lead rotation.
RAMSEY: ATV2500 / ATV3000
SUPERWINCH: Terra25 / Terra35 / Terra 45 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
MASTER LOCK: 1500lbs #2955AT
Requires roller fairlead with a 4.875″ bolt pattern;
CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
BADLAND: 2-Hole Winches
BADLAND: Standard Winches
BADLAND: WIDE Winches
CHAMPION: 2-Hole Winches
CHAMPION: Standard Winches
CHAMPION: WIDE Winches
KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C / KT4000 / KT4000C
KEEPER CORP. TRAKKER: KT2000
Requires roller fairlead with a 4.875″ bolt pattern;
SMITTYBILT: XRC 2.0
Requires roller fairlead with a 4.875″ bolt pattern;
Listed models come with incorrect ATV roller fairleads.
SMITTYBILT: XRC 3.0 / XRC 4.0
XGEAR: X3000 / X4000
4-Hole Standard (3.00″ x 4.875″ bolt pattern)
VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series)
All with 3.00″ x 4.875″ bolt pattern mount-up
All with 3.00″ x 6.600″ bolt pattern mount-up
Traveller: 1078311 (1078311 Will NOT work on 2014-2015 models)
Traveller: 1078088 / 1078302
Requires roller fairlead with a 4.875″ bolt pattern;
Possibly many others with the below standard mounting patterns, call to confirm.
4-Hole (3.00″ x 4.875″ bolt pattern with rollers that are 4.875″ bolt pattern)
4-Hole WIDE (3.00″ x 6.60″ bolt pattern with rollers that are 6.600″ or 6.000″ bolt pattern)
2-Hole (3.10″ with rollers that are 4.875″ bolt pattern)
QUADBOSS: RP25 / RP35
