Front Axles & Bearings or Polaris Magnum 500 & Sportsman 700 2002, 1380153
Front Axles & Bearings or Polaris Magnum 500 & Sportsman 700 2002, 1380153
Front Axles & Bearings or Polaris Magnum 500 & Sportsman 700 2002, 1380153
Description
This is a pair of CV axles with wheel bearings for a Polaris ATV.
They fit FRONT, LEFT & RIGHT on the following models:
2002 … Sportsman 700 -only models built before 05/01/2002
2002 … Magnum 500 4×4 A02CD50AA -without HDS Visco-Lok
*made as an OE replacement, and not intended for lifted/ modified vehicles
Product features:
Stronger than OEM, 4340 chromoly steel axle bars
Uses high-performance moly grease to keep vital components lubricated
Fitted with neoprene boots for added flexibility and resistance to hot/cold temperatures
High speed bearings manufactured for long life
Double lip seals made to keep grease in and dirt out
Inboard CV joint spline count: 22 (both)
Outboard CV joint spline count: 20 (both)
Compressed overall axle length: 494 mm (both)
Replaces OEM # (axles) 1380153, (bearings) 3514342, 3514634
