Weight 24 lbs
Height 4.5 in
Width 4.5 in
Length 31.4 in
ABS Ring Included No
Axle Boot Material Neoprene
Axle Nut Hex Size 1.38 in / 35 mm
Axle Nut Included Yes
Axle Nut Locking Type Split Pin
Axle Nut Thread Size M28 x 1.5
Boot Color Black
Cotter Pin Included No
Drive Type 4WD
Fitment Type Direct Replacement
Grease Type Molybdenum Disulfide Lithium Grease
Hardware Included No
Hazardous Material No
Inboard Clip Included Snap Ring
Input Shaft Connection Style Spline
ISO Specification ISO 16949
Items Included N/A
Number of Inboard Splines 30 Teeth
Number of Outboard Splines 30 Teeth
Output Shaft Connection Style Spline
Overall Compressed Length 25.47 in / 647 mm
Shaft Material 40CR
Surface Finish Black Coating
Transmission Type Automatic, Manual
