TrakMotive Front CV Axle Shaft Set for 2017-2018 Toyota Yaris iA (KIT705)
Includes Front Left & Front Right
Fitment Chart:
Years Make Model Transmission
2017-2018 Toyota Yaris iA Automatic
Specifications:
Part Category: CV Axle Shaft
Manufacturer Part Number: Kit-705
Vehicle Position: Front Left, Front Right
Placement on Vehicle: Front
Label: CV Axle Shaft
Product Type: Factory Replacement
Type: CV Axle Shaft
Abs Tone Ring Included: No
Axle Nut Head Type: Hex
Axle Nut Height (in): 0.85
Axle Nut Height (mm): 21.5
Axle Nut Hex Size (in): 1.18
Axle Nut Hex Size (mm): 30
Axle Nut Included: Yes
Axle Nut Length (in): 1.36
Axle Nut Length (mm): 34.64
Axle Nut Locking Type: Stake
Axle Nut Thread Size: M22*1.5
Boot Material: Neoprene
Inboard Joint Type: Male,male+long
Inboard Shaft Connection Style: Spline
New Or Remanufactured: New
Number Of Inboard Splines: /,26
Number Of Outboard Splines: 26,30
Outboard Joint Type: Conventional
Outboard Shaft Connection Style: Spline
Overall Compressed Length (in): 24.09,37.13
Overall Compressed Length (mm): 612,943
Interchange Part Number: 43410WB001 43410WB003 43420WB001 43420WB003 TO-8438 TO-8439
