Triple Tree
Fitment : Alloy Triple Fit 7/8” 22mm Handle Bar 45/48mm Front Fork Chinese Made Dirt Pit Bike.
Front Forks
Length — 700mm (from leg top to wheel axle center)
Upper Leg Diameter — 45mm (Triple Clamp Inner Diameter should be 1-1.5mm bigger than this figure)
Lower Leg Diameter — 48mm
Size detail as the picture shows.
Fit : Chinese motor bike : Tianzhong, Zongshen, TTR, Taotao etc.. as picture shows.
Triple tree clamp
Centre Pole: 240mm
Bolt distance: 155mm
45mm top clamp,
48mm bottom clamp
Bearing: 44-22-23.5mm (It is very important to check centre pole length and bearing size to confirm if it fit your headtube fram before order)
Wheels Rim Tire
Diameter of the axle hole: 15mm
Wheel Size: 70/100-17 17 inch rim+tube+tyre.
Package Include:
1x Wheel Rim Tire + 1 x Inner tube + 1 x Brake disc + 1 x Master cylinder Brake Caliper + 1 x Rim axle + 2 x Fork assembly +1 x Triple clamp handlebar riser set
