Description
New vacuum type fuel valve / petcock for the Honda models listed.

Check the threading on your bike to be sure this is what you need before you buy.

Measure the outer diameter of the threaded outlet on the gas tank, not the inner diameter of the petcock nut.

On / Off / Reserve. Plastic fuel filter. Fuel exits to the back. Comes with rubber sealing washer for a tight fit with no leaks

Threading: 18 x 1.0mm

24mm hex nut

Ribbed fuel outlet 8.6mm Outer Diameter
Replaces part numbers:16951-MF5-015 , 16950-MM2-013 , 16950-MM2-003 , 16950-MF8-771
Similar to part numbers: (Original fuel exit to the right)
16950-MC9-830 , 16950-ME2-010 , 16950-ME2-000 , 16950-MM9-013 Fits For Honda:
CMX450C Rebel – 1986-1987
VT500C Shadow 500 – 1983-1985
VT500FT Ascot – 1984
CB550SC Nighthawk – 1983
CB650SC Nighthawk – 1983-1985 Fits For Honda: (Original fuel exit to the right)
CB450SC Nighthawk – 1982-1986
FT500 Ascot – 1982-1983
GL500 Silver Wing – 1981-1982
GL500I Silver Wing Interstate – 1981-1982
XL600V Transalp – 1989-1990
GL650 Silver Wing – 1983
GL650I Silver Wing Interstate – 1983
