roductFeatures:
Advanced aerodynamics & ultra high flow GTX GEN2 compressor wheel
Forged aluminum compressor wheel
Machined speed sensor port
Light weight backplate
Oil cooled bearing housing (no water ports)
Dual ball bearing CHRA rotating assembly
Product Specifications:
Compressor Wheel Inducer: 91mm
Compressor Wheel Exducer: 133mm
Compressor Wheel Trim: 54
Turbine Wheel Inducer: 112mm
Turbine Wheel Exducer: 102mm
Turbine Wheel Trim: 84
Coolant (Water) & Oil Fittings, Flanges, and Components Solutions:
Oil feed flange: Product Code: ATP-FLA-008
Oil feed gasket: Product Code: GRT-GSK-011
Oil drain flange: Product Code: ATP-FLA-035
Oil drain gasket: Product Code: GRT-GSK-035
T6 Inlet Flange (for Turbo Manifold): Product Code:ATP-FLS-010
T6 Gasket: Product Code:ATP-GSK-017
V-Band Outlet Flange (for Downpipe): Product Code:ATP-FLS-092
V-Band Outlet Clamp: Product Code:CLC-CLA-022
