More information about the product V-belt Z29.5Li travel drive
Outer length: La795mm
Working length: Lw782mm
Inner length: Li750mm
Width: 10mm(3/8″)
Height: 6mm
Manufacturer: MITSUBOSHI 10x750Li Z-29.5”
Replacement / Original No. – 5019866-01
Application: Brand Models / Type
HUSQVARNA LC48V, LC48VE, LC348V, LB 248S, LB348SI, LB348V Classic, LB48E, LB48V, LC148VE, LC348V Classic, LC348VE, LC348VI Classic, LC48V, LC48, LC48BE, LC48E, LC48VE, M148SV, R148
How to measure a belt:
Outer circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure in an arc on the outside (with a tailor’s tape).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Inner circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt that is 10mm (3/8″) or 17mm (5/8″) wide.
