More product information Travel drive belt88″La
Outer length: La2242mm
Working length: Lw2224mm
Internal length: Li2185mm
Width:13mm (1/2″)
Height: 8mm
Manufacturer: Kramp FGP013476
Application: Brand replacement /
no. original Models/Type HUSQVARNA 5321245-25, 5310050-25 LR100, LR110, LR111, LR12, LR120, LR121, LR125, LT112 POULAN PP1036, PP1136, PP11536K, PP1236, PP125R38, PP21R38
How to measure a belt:
Outer Circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure with an arc on the outside (with a tailor’s tape measure).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Internal circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt that is 10mm (3/8″) or 17mm (5/8″) wide.
