More product information 92″La drive belt.
Outer length: La2340mm
Working length: Lw2320mm
Inside length: Li2282mm
Width: 13mm (1/2″)
Height: 8mm
Manufacturer: Kramp FGP013480
Replacement / Original No. – 5321309-69
Application: Brand Models / Type
BERNARD BL1442LT, BL1542LTD – HUSQVARNA blade drive LTH152 (2010-13), LTH154 (2012-13), LTH171, LTH174 (2011-13), TS238 (2014-15), TS242 (2014-17), TS243 (2014-16), TS246 (2015-17), TS342 (2014-17), TS348 (2015-17), YTH184T (2011-13) MCCULLOCH M145-107T
How to measure a belt:
Outer Circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure with an arc on the outside (with a tailor’s tape measure).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Internal circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt that is 10mm (3/8″) or 17mm (5/8″) wide.
