Hydraulic Top Link Cat. 2-2 with Locking Block 21 5/8?? - 32 11/16?? with 2 x Hose
Hydraulic Top Link Cat. 2-2 with Locking Block 21 5/8?? - 32 11/16?? with 2 x Hose - Image 2

Hydraulic Top Link Cat. 2-2 with Locking Block 21 5/8?? – 32 11/16?? with 2 x Hose

SKU GJ.24370 Category Tag

Hydraulic Top Link Cat. 2-2 with Locking Block 21 5/8?? – 32 11/16?? with 2 x Hose

Description

Technical specifications:
Category: 2
Pin hole: 1 ”
Cylinder bore: 2″
Rod diameter: 1 3/16″
Hydraulic pressure max. 250 bar
Thrust: 3.5 to
Pulling force: 2.3 to
Weight about 10.35 kg
+
2 x hydraulic hose with plug and dust cover
Technical specifications:
Connection: 12-L bulkhead size 3 (usual coupling connector), 18-1.5 SW22 nipple + union
Hose designation Blue Flex SAE 100 3/8 R2AT DIN EN 853 2SN DN10 W.P.330
Operating pressure: 180 bar
Length: 70 cm
