Mono Shock Absorber Rear for Honda NX 250 1988

SKU 1153 789.05.25 Category Tag

Mono Shock Absorber Rear for Honda NX 250 1988

Post date

July 2, 2024 - Updated on July 2, 2024

Description

Body in milled aluminum. Shock absorbing unit in preload and rebound (60ks) adjustable: fine thread on top and manually rubberized adjustment.
Locking screw set.
Adjustable in length to +5mm and -5mm
Technical data: Type5: Gas emulsion shock absorber
Upper fixing: Eyelet
Diameter: 10 mm
Length: 315/325 mm
Lower fixing: Fork
Fork width: 30 mm
Adjustment: Preload (continuous) / Rebound
Spring color: Red
Spring characteristics: 46-115-150
Tanks: No
Manufacturer: YSS
Piston diameter: 36 mm
Stem diameter: 12 mm
