About 15-1/4″ overall, compressed spring’s about 7-3/8″ (soft setting), spring o. d.’s about 2-13/16″, ends are .790″ i.d. x .870″ wide, weighs 4 lbs, 5 oz.,
comes without bushings, axle, bolts or nuts.
ASSEMBLIES WHERE 8GJ-2376A-20-00 IS USED
2008 Venture Lite (PZ50VTXL) – Ski
2008 Venture Lite (PZ50VTXR) – Ski
2009 Venture Lite (PZ50VTYR) – Ski
2009 Venture Lite (PZ50VTYS) – Ski
2010 Venture Lite (PZ50VTZL) – Ski
2010 Venture Lite (PZ50VTZR) – Ski
2011 Venture Lite (PZ50VTAW) – Ski
2012 Venture Lite (PZ50VTBL) – Ski
2012 Venture Lite (PZ50VTBW) – Ski
2013 Venture Lite (PZ50VTDR) – Ski
