DetailsKoso RX4 speedometer for YAMAHA MT-07 / MT-09 / XSR700 / XSR900Koso RX4 multifunction odometer specific for the following YAMAHA models:
for YAMAHA MT-07 (2014-2020)
for YAMAHA MT-09 (2014-2016)
for YAMAHA XSR700 (2015-2021)
for YAMAHA XSR900 (2016-2021)
Extra featuresThe RX4 is not just a simple instrument cluster with standard functions such as speed, rpm, gear indicator, voltage, clock, fuel level and so on, but also displays many other important information. For example, you can connect your mobile phone via Bluetooth to view incoming calls, satellite navigation, estimated time of arrival and much more.The RX4 is a Plug & Play device, just connect it to the original wiring and you’re done. To accommodate growing connectivity, the RX4 features a large LCD screen with excellent readability, numerous display options and high ease of use. The backlight color is adjustable, with a choice of 4 color schemes.Note: for MT-07 (2017-2020) no additional bracket is needed. For MT-09 / XSR700 the following brackets are required:
Bracket for YAMAHA XSR700: cod. BE081000
Bracket for YAMAHA MT-09: cod. BE081020
Features and settings
Odometer: 0 – 360 km/h
Odometer: 0 – 999.999 km
Trip odometer: 0 – 9,999.9 km
Maximum speed memory
Tachometer: 0 – 12,000 rpm or 0 – 13,000 rpm depending on the model
Gear indicator N, 1 – 6 and shift Flash
oil maintenance intervals with alarm function
Thermometer: – 10 to 100 ??C
6-step fuel level, including fuel alarm
Current and average fuel consumption
Riding Modes: STD, A, B and ECO display
Voltmeter with warning function
Tire pressure: 0 – 3.5 bar
Grip heating ON / 50% / 100%
Target speed / target distance
Bluetooth
Mobile phone battery: 3 bar
Cell phone indicators: incoming calls, messages, ETA, song titles, etc.
Indicator lights for turn signals, high beams, ABS, engine, TCS monitoring, coolant temperature, idle and more
Dimensions: 170 x 86.2 x 42.5 mm
