Premium Quality Replacement Part
Primary Drive Clutch Rebuild Kit
For Polaris Models:
Sportsman 450 HO EPS 2019-2022
Sportsman 450 HO EPS Utility 2020-2024
Sportsman 450 HO EPS 50S 2023-2024
Sportsman 570 EFI 2019-2024
Sportsman 570 EPS ZUG 2019-2024
Sportsman 570 EPS Utility 2021-2022
Sportsman Touring 570 EPS SP Tractor 2019-2023
Sportsman 570 X2 EU/ZUG 2019-2023
Sportsman 570 Premium 2020-2022
Sportsman 570 Euro 6X6 2019-2023
Order Includes:
3 x Clutch Weight : 5632409
PRING CLUTCH 35-2405632409 / CW110
3 x Roller : 1321457 5020433
Outer Diameter : 14.3 mm – 0.56″
Inner Diameter : 9.5 mm – 0.37″
Width : 9 mm – 0.35″
3 x Roller Pin: 5020422
Length : 25 mm – 0.98″
Outer Diameter : 9.5 mm – 0.37″
6 x Roller Washer : 5438247 5430702 5430945
Outer Diameter : 14.6 mm – 0.57″
Inner Diameter : 9.6 mm – 0.37″
Thickness : 1.5 mm – 0.059″
6 x Button : 5439254 5431936
Outer Diameter: 14 mm – 0.55″
Width : 6.5 mm – 0.25″
3 x Shoulder Bolt (Socket Head Cap Screw) : 7512266
Length : 63.8 mm – 2.51″M5x1.0
3 x Nut : 7541906 3235320
Inner Diameter : 4 mm – 0.15″
Height : 6.1 mm – 0.24″M5x1.0
