Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4x4 2007-2013
Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4x4 2007-2013 - Image 2
Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4x4 2007-2013 - Image 3
Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4x4 2007-2013 - Image 4
Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4x4 2007-2013 - Image 5

Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4×4 2007-2013

SKU LJQ.04783 41300-HP5-600, 41300HP5600, 40200-HP5-600, 40200HP5600 Category Tag

Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4×4 2007-2013

Description

Premium Quality Replacement Part
Rear Differential & Prop Shaft For Honda Rancher 420 TRX420FM 4×4 2007-2013
For Honda Models:Rancher 420 TRX420FM 4×4 2007-2013
Order Includes:
1x Propeller Shaft : 40200-HP5-600
Height : 223mm
Width : 21mm
1x Rear Deferential : 41300-HP5-600
Height : 216mm
Length : 178mm
Width : 152mm
Axle Diameter : 36mm
R Diferential Axle Teeth : 34
Spline diameter : 31mm
Spline teeth : 20
