ABS Tone Ring Included: No
Adjustable: No
Axle Shaft Seal Included: Yes
Brake Backing Plate Included: Yes
Brake Dust Shield Included: Yes
Brake Hardware Included: No
California Proposition 65: WARNING: Cancer and Reproductive Harm ?C www.P65Warnings.ca.gov
Compressed Length: 795 mm
Differential Case Design Type: Semi-Float
Feature – Benefit 1: Easier installation – this loaded axle assembly includes a new axle shaft, wheel bearing, hub and backing plate pre-assembled and ready to install right out of the box
Feature – Benefit 2: Time saver – eliminates frustrating, unpredictable work required to replace bearings without damaging other components
Feature – Benefit 3: Simpler solution – eliminates the need to use potentially dangerous shop press to perform complete bearing repair
Feature – Benefit 4: Trustworthy quality – backed by engineers and inspectors in the United States, with decades of aftermarket experience
Hub Bearing Included: Yes
Inboard Spline Quantity: 30
Length: 795 mm
Material: Carbon Steel
Outboard Spline Quantity: 30
Package Contents: 1 Axle Assembly; 1 Axle Housing Seal; 1 Axle Housing O-ring
Rust Resistant Coating: Yes
Shaft Diameter: 33.6
Wheel Bolt Pattern Size: 6 Lug x 139.7 mm
Wheel Stud Thread Diameter: 12
Wheel Stud Thread Pitch: 1.5
Wheel Studs Included: Yes
