More product information 83″LW Simplicity V-belt Outside length: La2110mm
Working length: Lw2092mm
Inside length Li2050mm
Width: 13mm(1/2″)
Height: 8mm
Manufacturer: Kramp FGP013471
Replacement / Original No. – 1604406SM,1721532SM
Application: Brand Models /Type
SIMPLICITY 1714G, 1716G, 1716H, 1718H, 1723H, 1825H, 2723H, 2825H, Landlord, Prestige, ZT (Zero Turn) – 44″ cutter 517H, 2517H, 4416XL, Broadmoor, Conquest, Lancer, Regent – 40″ cutter
How to measure a belt:
Outer Circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure with an arc on the outside (with a tailor’s tape measure).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Internal circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt that is 10mm (3/8″) or 17mm (5/8″) wide.
