Application:Compatible with Ford Triton 3 Valve 5.4L engine 2004-on.
Material:Made of Ultra-high strength iron with oil film, not easy to corrode, not easy to rust, firmness and durability, long service life.
Spark Plug Remove Tool Kit:A porcelain pusher for when the porcelain breaks off in the plug tip. A Self-Tapping Puller to remove the seized metal tip. A Porcelain Puller Tool that snaps onto the terminal of a broken spark plug to pull the porcelain out.
High Performance:The porcelain pusher is used to press the porcelain piece and farther into the plug tip without breaking the porcelain, which provides space for the left-hand thread remover to bite into the stainless steel plug tip so it can then be pulled.
Compatible with Ford Triton 3 Valve 5.4L engine 2004 and newer.
Compatible with Ford F150 pick up
Compatible with Ford Expedition
Compatible with Lincoln Navigator
Compatible with Lincoln Mark LT
Instructions
Use a 3/4″ socket to remove the pusher assembly.
The push screw hex should touch the body hex.
Blow out all the porcelain pieces and insert the puller housing.
Insert the pull screw and turn counterclockwise until tight. Use a 7/16″ socket.
Place the nylon washer and left hand nut on the pull screw. against the puller housing. Use a 15/16 inch socket.
Turn the nut counterclockwise to pull the damaged spark plug tip out of the hole. Use a 15/16 inch socket. Blow out all the china before inserting new spark plugs.
When all the porcelain comes out with the stopper and only the tip is left in the hole, the push rod assembly step can be skipped.
