More information about the product Tractor drive belt
Outer length: La2600mm
Working length: Lw2580mm
Inner length: Li2540mm
Width: 1/2″ (13mm)
Height: 7.5mm
Manufacturer:
Kramp FGP013392
Replacement / Original No. – 5816038-01
Application: Brand Models / Type MCCULLOCH M125-107T, M145-107T, M145-97T 960410377, M185-117T,M200-117T HUSQVARNA TS138, TS142
How to measure a belt:
Outer circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure in an arc on the outside (with a tailor’s tape).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Inner circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt with a
Width of 10mm (3/8″) or 17mm (5/8″).
