Features:
*Works with 36V Lead-Acid Batteries in Golf Carts, Forklifts, Trucks, RV’s, ATV’s, UTV’s, Scooters, Boats and More
*Material: ABS
*Waterproof, IP65
*Temperature Range: -40F to 185F
*Connection: Pin+ Battery+ Pin- Battery- C-single output for external use
Operation
*Only when the battery is properly charged then the 10th LED (far right) will be lighted.
*As battery??s state of charge decreases, successive LED lights up, only one at a time.
*When 2nd (from left) LED flashes, indicating “energy reserve”. When both 1st and 2nd LED flash, indicating “empty”, new battery is needed to replace old one.
*Battery indicator memorized the battery state is full when leaving factory. When use with a new battery, it should be powered on for at least 2 minutes to indicate the real battery state.
*Range indication: Green: 41~100%, Yellow: 21~40%, Red: 20% less.
*Applications: Forklift trucks, Golf Carts, RV’s, Boats, Scooters and electric vehicle. etc.
*Dimensions: Cut-off: 1.5″x1″, distance between holes: 1.75″, depth: 1.5″
*Case Style: Front Panel Mount
Package Contents
1 x 36V LED Battery Indicator Gauge
1 x Accessory
